Neodymium Oxide

Neodymium, atomic no. 60, symbol Nd, weight at 144.24, is the most abundant of the rare earths after cerium and lanthanum. It shows similar characteristics to the other trivalent lanthanides.
Primary applications include lasers, glass coloring and tinting, dielectrics and, most importantly, as the fundamental basis for neodymium-iron-boron (Nd2Fe14B) permanent magnets.
The neodymium-based magnet is used extensively in the automotive industry with many applications including starter motors, brake systems, seat adjusters and car stereo speakers. Its largest application is in the voice coil motors used in computer disk drives.
Neodymium has a strong absorption band centered at 580 nm, which is very close to the human eye's maximum level of sensitivity making it useful in protective lenses for welding goggles. It is also used in CRT displays to enhance contrast between reds and greens. It is highly valued in glass manufacturing for its attractive purple coloring to glass.

Available products

Product CAS1313-97-9
Chemical FormulaNd2O3
Main applicationsGlass; Ceramics; Alloy; Laser crystal; Electric capacitor; Rubber additives
5KG 10KG 15KG

Metal analysis

Standard Specifications

Product Code









Grade

99.999%

99.99%

99.9%

99%

CHEMICAL COMPOSITION









Nd2O3/TREO (% min.)

99.999

99.99

99.9

99

TREO (% min.)

99

99

99

99

Loss On Ignition (% max.)

1

1

1

1

Rare Earth Impurities

% max.

% max.

% max.

% max.

La2O3/TREO
CeO2/TREO
Pr6O11/TREO
Sm2O3/TREO
Eu2O3/TREO
Y2O3/TREO

0.0003
0.0003
0.0005
0.0005
0.0001
0.0001

0.005
0.0005
0.005
0.0003
0.0003
0.0003

0.01
0.01
0.05
0.03
0.01
0.01

0.05
0.05
0.5
0.05
0.05
0.03

Non-Rare Earth Impurities

% max.

% max.

% max.

% max.

Fe2O3
SiO2
CaO
CuO
PbO
NiO
Cl-

0.0005
0.003
0.005
0.0001
0.0001
0.0003
0.001

0.001
0.003
0.005
0.0002
0.0005
0.0005
0.005

0.001
0.005
0.005
0.002
0.001
0.001
0.02

0.005
0.02
0.01
0.005
0.002
0.001
0.02

Discription

Neodymium Oxide is a kind of light purple powder. It is mainly used as a coloring in making glass and ceramics, and it is also used as the raw material for making neodymium metal and magnetic Nd-Fe-B.

Packing

In plastic woven bag with inner double PVC bags of 500kg net each, as well as according to customers' requirements.
